Layer3 switch 24 ports 1000Mbps POE switch 4 port 10G SFP Managed network switch giga 24 port

Model: SY-24G410G4SMP Uncategorized 10G 3Layer Managed POE Switch Managed POE Switch

Key Features:

  • Compatible with IEEE 802.1d、IEEE 802.1w、IEEE 802.1s、IEEE 802.1p、IEEE 802.3、IEEE 802.3u、IEEE 802.3x、IEEE 802.3z、IEEE 802.3ab、IEEE 802.3ae standard;
  • L3 Management,support DHCP Server, QoS, ACL control, support SNMP V1/V2/V3, support IGMP Snooping v1/v2;
  • Support Spanning Tree Protocol STP/RSTP/MSTP (ERPS), Support loop detection and self-healing, support remote loopback monitoring and control (802.3ah OAM);
  • Support multiple VLAN divisions, mac VLAN, protocol VLAN, private VLAN;
  • Support IP address + MAC address + VLAN + port binding, support DHCP Snooping, support IP source and DAI protection;
  • Support IPV4/IPV6,RIP,OSPF;
  • Compatible with IEEE802.3at (30W) and IEEE802.3af (15.4w) power supply standards;
  • Support PoE management, PoE watchdog;

Share it:

Share it:

Interested?

Welcome to Contact Us for a Quotation!

Ship within 7-10 Working Days for Stocking Products,Customized product should be negotiated

Specifications

Product model SY-24G410G4SMP
Total Power of Machine 400W
Power AC100-240V/50-60Hz
Ethernet 24*10/100/1000Mbps POE Port
4*10G SFP + Port 1*RJ45 Console Port
1*USB Port
Switching Capacity 128Gbps
Packet Buffer Memory 12Mbit
Flash Memory 16MB
DDR SDRAM 128MB
MAC Address 16K
Jumbo Frame 12Kbytes
Transfer Mode Store and forward
MTBF 100000 hour
Power Voltage
Input voltage: AC100-240V/50-60Hz
 Power supply: 52V 7.5A 12V4A
Working Environment Working Temperature: -10~50°C

Storage Temperature: -40~70°C
Working Humidity: 10%~90%,

non-condensing Storage Temperature: 5%~90%, non-condensing

SY-24G410G4SMP is 28 Port 10G Uplink 24 Port Gigabit L3 Managed Ethernet POE Switch, which provide 24*10/100/1000 adaptive POE electrical port, 4*10G SFP+ Port,1*Console port, 1*USB series port. Used the high quality high speed network IC and the most stable POE chips, POE port satisified IEEE 802.3 af/at standard, this series POE Switch can provide no gap link for 10/100/1000M ethernet, and the PoE power supply port can automatically detect and supply power to the power receiving device that meets the standard, intelligent detection of non-PoE devices does not supply power, only transmits data. Completed security control strategy and CPU protect policy improve fault tolerance, ensure stable network operation and link load balance; equipment supports automatic DoS attack prevention and SNMP, IEEE 802.1, spanning tree and rapid spanning tree protocol, link aggregation and other functions . With advanced security functions and quality of service (QoS) , it can be used as core layer, distribution layer ,and access layer switch with high density port and easy management, is an ideal choice for various business network applications.
